Beskrivelse
- Frame:Raze 29 Stealth Air full Carbon
- Zero Suspension System:
- 130mm travel:
- Forward Geometry:
- Carbon Monoblock upper link:
- Boost 12x148mm rear axle:
- tapered head tube:
- 73mm BSA bottom bracket:
- dedicated 1x drivetrain design:
- HHG internal cable routing:
- Enduro MAX sealed bearings:
- shock mudguard:
- ISCG 05:
- custom frame protectors. :
- Frame:S
- Frame:Fox Float EVOL Performance
- 205×57.5mm. Settings: 2-position compression adjustment (Open/Firm)
- rebound:
- air preload. Trunnion top mount:
- 30x8mm bottom bushings :
- Frame:Light compression
- light rebound:
- air volume spacer 0.6:
- Frame:Fox 36 29 Float GRIP EVOL Performance
- 150mm:
- tapered steerer tube:
- Boost 15x110mm axle:
- 44mm offset. Settings: 3 positions with micro adjust compression
- low-speed rebound:
- air preload:
- Frame:Onoff Sulfur FG 30mm 0º
- 6061 forged alloy:
- 31.8mm barbore:
- Frame:Onoff Sulfur 1.0 double butted 6061 alloy
- rise: 20mm
- width: 800mm
- 9º backsweep:
- 5º upsweep:
- 31.8mm barbore:
- Frame:Onoff Desert
- 1lock-on:
- 135mm:
- Frame:Onoff Pija dropper internal
- diameter 31.6mm:
- 1X Remote lever with bearing:
- S size: 405×95-125mm
- M size: 458×120-150mm
- L size: 498×140-170mm
- XL size: 558×170-200mm
- Frame:Fizik Vento Argo X5
- Frame:Sram G2 R
- 4-piston caliper:
- Centerline 180mm IS 6 bolts one-piece rotor:
- steel-backed organic pads:
- Frame:Sram G2 R
- 4-piston caliper:
- Centerline 180mm IS 6 bolts one-piece rotor:
- steel-backed organic pads:
- Frame:Sram G2 R
- tool-free reach adjust:
- lever pivot bushings:
- Frame:Mavic CrossMax XL S
- 29 Boost 30mm internal width:
- hookless:
- tubeless ready:
- 24 spokes:
- Frame:Mavic 24 straight-pull double butted spokes
- Frame:Mavic Infinity hub
- Boost 15x110mm:
- IS 6 bolts:
- Frame:Mavic Infinity hub
- ID360 freewheel technology:
- Boost 12x148mm:
- IS 6 bolts:
- XD freehub:
- Frame:Maxxis Dissector 29×2.4 WT
- tubeless ready:
- 3C MAXX TERRA compound:
- EXO+ protection:
- 120TPI:
- folding bead:
- Frame:Maxxis Aggressor 29×2.3
- tubeless ready:
- dual compound:
- Exo protection:
- 60TPI:
- folding bead:
- Frame:Truvativ Stylo 7k Eagle
- Boost:
- DUB axle:
- Direct mount chain ring:
- S size: 170mm M size
- CL 52 :
- Frame:32T
- CNC-machined alloy:
- X-SYNC 2:
- Frame:Sram DUB BSA
- sealed bearings:
- 73mm:
- Frame:Sram NX Eagle
- 12s:
- Powerlock:
- Frame:Sram GX Eagle
- Type 3 roller bearing clutch:
- cage lock:
- 1x12s:
- X-Actuation 1:1
- Frame:Sram Trigger NX Eagle
- 12s:
- X-Actuation 1:1
- Frame:Sram XG-1275
- 10-52T:
- 12s:
- Frame:Sram UDH
- :
